6BTA5.9-M150 with gearbox

FOB Reference Price:Get Latest Price
US $2,000-20,000 / Units | 1 Unit/Units (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Engine:
4 Stroke
Engine Capacity:
> 6L
Fuel Type:
Diesel
Cylinders:
6
Engine Position:
Inboard
Dimensions (L x W x H) (mm):
1404.9*767.5*1178.7
SupplyAbility
SupplyAbility:
10000 Unit/Units per Month
Packaging & Delivery
Packaging Details
WOODEN BOX
Port
SHANGHAI
Lead Time :
1 MONTH
cummins marine engine 6BT5.9-M150

6BT5.9-M150

General

Displacement5.9L

Bore102mm

Cylinders6

Stroke120mm

Fuel SystemAD/RSV

Technical Specification

AspirationTurbocharged

Turning"contrarotate

(face to flywheel)"

Performance Data

Advertised Power/Speed 150HP/2100RPM

Marine gearbox HCD138 5.05:1



DCEC-Cummins marine main engine

Model Rated Power (kw/rpm) Max Power (kw/rpm) Intake Way
6BTA5.9-M150 110/2200 120/2200 Turbocharged and intercooled
6CTA8.3-M188 138/2328 152/2328 Turbocharged and intercooled
6CTA8.3-M205 151/2328 166/2328 Turbocharged and intercooled
6CTA8.3-M220 164/1800 180/1800 Turbocharged and intercooled
6CTAA8.3-M260 190/2134 209/2134 Turbocharged and air to air intercooled
6LTAA8.9-M300 224/1800 245/1800 Turbocharged and air to air intercooled
6LTAA8.9-M315 230/2134 253/2134 Turbocharged and air to air intercooled
Note:All the aboce engine model have got the type approval certification of CCS.Some have procured IMO emission certification.
DCEC-Cummins marine main engine
ModelRated Power (kw/rpm)Max Power (kw/rpm)Intake Way
6BTA5.9-M150110/2200120/2200Turbocharged and intercooled
6CTA8.3-M188138/2328152/2328Turbocharged and intercooled
6CTA8.3-M205151/2328166/2328Turbocharged and intercooled
6CTA8.3-M220164/1800180/1800Turbocharged and intercooled
6CTAA8.3-M260190/2134209/2134Turbocharged and air to air intercooled
6LTAA8.9-M300224/1800245/1800Turbocharged and air to air intercooled
6LTAA8.9-M315230/2134253/2134Turbocharged and air to air intercooled
Note:All the aboce engine model have got the type approval certification of CCS.Some have procured IMO emission certification.
